Three Phase PM Synchronous Motor

It is a motor developed by our company with rare-earth materials in response to the national call for energy savings and emission reduction. It has the advantages of a high overload capacity, high efficiency, a high power factor, stable operation, and simple maintenance. Including the JPM series (specially designed for screw-type air compressors), the JPM series (applied for general industry), the YP series ( horizontal type), the YTPM series (integrated type), and the JPMBP series.

All Three Phase PM Synchronous Motor



JPM Series Three Phase Permanent Magnet Synchronous Motor (Specially Designed For Air Compressor)
JPM Series Three Phase Permanent Magnet Synchronous Motor (Specially Designed For Air Compressor)
  • This series of motors is an energy-saving motor for the compressor. The motor can change the speed with the gas volume and maintain high efficiency under loading and unloading conditions.
  • The actual margin of the motor is sufficient to ensure the reliable operation of the motor at full load with low temperature rise.
  • Its efficient operation range is wide and the efficiency is more than 90% in the range of 25%~120%. The efficiency is higher than the lever 1 of GB30253-2013.
  • It is perfectly matching with the air compressor, boosting air compressor overall efficiency far more than the national standard level 1 energy efficiency.
JPM Series Three Phase Permanent Magnet Synchronous Motor (Applied For General Industry)
JPM Series Three Phase Permanent Magnet Synchronous Motor (Applied For General Industry)
  • It adopts standard fully enclosed structure which can meet the stable operation under a variety of harsh working conditions.
  • The actual margin of the motor is sufficient to ensure the reliable operation of the motor at full load with low temperature rise.
  • Its efficient operation range is wide and the efficiency is more than 90% in the range of 25%~120%. The efficiency is higher than the lever 1 of GB30253-2013.
  • Small volume, high output power and high efficiency.
YTPM Series Three Phase Permanent Magnet Synchronous Motor (Integrated Type Specially Designed For Air Compressor)
YTPM Series Three Phase Permanent Magnet Synchronous Motor (Integrated Type Specially Designed For Air Compressor)
  • Special stator slot and rotor structure,low loss silicon steel sheet,high brand permanent magnet material, high utilization rate of magnetic field;The motor efficiency is higher than the first-level energy efficiency requirement of the energy efficiency standard gb30253-2013, and far higher than IE4.
  • The actual margin of the motor is sufficient to ensure the reliable operation of the motor at full load with low temperature rise.
  • Professional optimization performance design, small motor inertia, wide operating frequency, low speed running torque smooth no fluctuation.
  • By changing the excessive flange and shaft sleeve can be adopted to a variety of machine head ( Hanbell and BSC brand, etc.)
YP Series Three Phase Permanent Magnet Synchronous Motor (Horizontal Type Specially Designed For Air Compressor)
YP Series Three Phase Permanent Magnet Synchronous Motor (Horizontal Type Specially Designed For Air Compressor)
  • Special stator slot and rotor structure,low loss silicon steel sheet,high brand permanent magnet material, high utilization rate of magnetic field;The motor efficiency is higher than the first-level energy efficiency requirement of the energy efficiency standard gb30253-2013, and far higher than IE4.
  • The motor structure is semi-closed structure. The internal heat of the motor directly through the external air flow exchange and the heat exchange rate is high. The winding temperature and the magnetic steel are low.
  • Professional optimization performance design, small motor inertia, wide operating frequency, low speed running torque smooth no fluctuation.
  • It is specially designed for horizontal bipolar machine head.
JPMBP Series Flameproof Three Phase Permanent Magnet Synchronous Motor
JPMBP Series Flameproof Three Phase Permanent Magnet Synchronous Motor
  • It is a derivative of JPM series three phase permanent magnet synchronous motor.
  • High overload capacity, high efficiency, high power factor.
  • Cooling method: IC416.
  • It has two kinds of ExdbIIAT4Gb、ExdbIIBT4Gb.

More Thoughtful Motor Solutions for Your Industry

Powerful and long-lasting power for a wide range of industrial equipment.

How Can We Help?



Inquiry

A preliminary Quotation

Confirm the Technical Requirements and Drawings

Confirm the Contract Details, Including the Motor Specifications, Model, Quantity, Commercial Terms, Etc.

Arrange the Deposit As Required on the Contract

Production

The Customer Arranges the Balance

Delivery and Providing the Relevant Proof

Professional Development, Production and Sales of High Efficiency Motor

The company has over 200 sets of special equipment, including various machining centers, high-speed punching machines, automatic wire embedding machines, vacuum dipping paint machines, assembly lines, etc. With a strong capacity for the self-production of parts and components, we can produce 300,000 sets and 8 million kilowatts of various motors annually, such as low-voltage, explosion-proof, permanent magnet synchronous, high-voltage, and servo motors.

Every High Efficiency Motor , Safety Guaranteed

We employ more than 50 professionals in various quality management, inspection, and testing roles, of which 70% are above college level. We have established a complete quality control system from raw materials incoming to finished products, equipped with various material analyzers, silent test rooms, CNAS national experimental stations, and other testing equipment and facilities.

High Efficiency Motor Technologies



Which kinds of motor products can you produce?
We can produce all kinds of low-voltage three-phase asynchronous motors, explosion-proof motors, three-phase PM synchronous motors, high-voltage three-phase asynchronous motors, and servo motors of the 20 series.
How about the energy efficiency grade of your products?
Our products can meet levels 3 (YE3 and YBT series), level 2 (YE4 and YBT4 series), and level 1 (YE5 and PM series) of the energy efficiency limit value of the GB18613-2020 standard.
What is the power range of your motor?
We can produce a power range of 0.55–800 KW.
What is the protection grade of your motor?
We have IP23 ( LY, YTPM, and Y series) and IP55( YE3, YE4, YE5, and JPM series).
What is the voltage of your motor?
We generally produce 6000V and 1000V for high-voltage motors and 380 V for low-voltage motors. It can also be customized according to the customer's requirements.
What is the frequency of your motor?
We generally produce 50 HZ motors. It can also be customized according to the customer's requirements.
What kind of working environment is the motor suitable for?
Our motor working environment is -15 to 40°C and has an altitude below 1000 m. It can also be customized according to the customer's requirements.
